![Airwell MQL17 [27/40] Technical data](/views2/1409105/page27/bg1b.png)
Page 26
Technical data
MQH 4 6 8M 8T
Power supply
V/ph/Hz
220V-1-50Hz 220V-1-50Hz 220V-1-50Hz 400/3+N/50
Number of circuits 1111
Number of steps 0-100 0-100 0-100 0-100
Refrigerant
Type R407C
Charge (1) kg 1.2 2.1 2 2
Compressors
Type Rotating Rotating Scroll Scroll
Number 1111
Start-up type Direct
Evaporator
Type Slabs
Number 1111
Condenser
Type Battery (Al/Cu)
Hydraulic connections
Type Female
Inlet diameter inch 1” 1” 1” 1”
Outlet diameter inch 1” 1” 1” 1”
Weights
Weight of shipment kg 97 104 110 110
Dimensions
Length mm 1182 1182 1182 1182
Width mm 400 400 400 400
Height mm 905 905 905 905
(1) Indicative value. Always refer to the value specified on the unit’s label.
