On/Off The Switch works improperly.
On
A
1000 Mbps device is connected to the corresponding port, but no
activity.
Green
Flashing Data is being transmitted or received
On
A 10/100 Mbps device is connected to the corresponding port, but
no activity.
Yellow
Flashing Data is being transmitted or received
10/100/
1000
Mbps
Port LED
Off No device is connected to the corresponding port
When the PoE LED is on, the port LED is indicating the power supply status.
LED Status Indication
On The Switch is powered on.
Off The Switch is powered off or power supply is abnormal.
Power
Flashing Power supply is abnormal.
Flashing The Switch works properly.
System
On/Off The Switch works improperly.
On The remaining PoE power≤7W.
Flashing
The remaining PoE power keeps ≤7W after this LED is on for 2
minutes.
PoE Max
Off The remaining PoE power≥7W.
On The port is supplying power normally.
Green
Flashing The supply power exceeds the correspond port’s maximum power.
On Overload or short circuit is detected.
Yellow
Flashing Power-on self-test has failed.
10/100/
1000
Mbps
Port LED
Off No PoE power supply is provided on the port.
8
