¾ Configuration Procedure

z Configure Switch A

Step Operation Description

1 Configure the

Link Type of the

ports

Required. On VLAN→802.1Q VLAN→Port Config page, configure

the link type of Port 2, Port 3 and Port 4 as ACCESS, TRUNK and

ACCESS respectively

2 Create VLAN10 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLANID as 10, owning Port 2 and Port 3.

3 Create VLAN20 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLANID as 20, owning Port 3 and Port 4.

z Configure Switch B

Step Operation Description

1 Configure the

Link Type of the

ports

Required. On VLAN→802.1Q VLAN→Port Config page, configure

the link type of Port 7, Port 6 and Port 8 as ACCESS, TRUNK and

ACCESS respectively.

2 Create VLAN10 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLANID as 10, owning Port 6 and Port 8.

3 Create VLAN20 Required. On VLAN→802.1Q VLAN→VLAN Config page, create a

VLAN with its VLANID as 20, owning Port 6 and Port 7.

6.5 Application Example for MAC VLAN

¾ Network Requirements

z Switch A and Switch B are connected to meeting room A and meeting room B respectively, and

the two rooms are for all departments;

z Notebook A and Notebook B, special for meeting room, are of two different departments;

z The two departments are in VLAN10 and VLAN20 respectively. The two notebooks can just

access the server of their own departments, that is, Server A and Server B, in the two meeting

rooms;

z The MAC address of Notebook A is 00-19-56-8A-4C-71, Notebook B’s MAC address is

00-19-56-82-3B-70.

¾ Network Diagram
