TL-R460 Cable/DSL Router User Guide

shown in Figure 4-23.

Step 2: Select the service you want from the “Common Service Port”, then the port and

protocol value will be added to the corresponding field automatically, you only

need to configure the IP address for the virtual server; If the “Common Service

Port” does not contain the service that you want, please configure the Service

Port, IP Address and Protocol manually.

Figure 4-23

Step 3: After that, select Enabled to make the entry take effect.

Step 4: Click Save button to save the configuration.

)

Note:

1) If you want to add more than one reserved IP, please go to step 1 to continue.

2) It is possible that you configure more than one type of available service on a

computer or server, it means the IP addresses for the virtual servers are same.

Other configurations for the entries as shown in Figure 4-23:

Click the Delete button to delete the entry.

Click the Enable All button to enable all the entries.

Click the Disable All button to disable all the entries.

Click the Delete All button to delete all the entries.

Click the Previous button to view the information on the previous screen, click the Next

button to view the information on the next screen.

)

Note:

If you set the virtual server of the service port as 80, you must set the web management

port on Security –> Remote Management screen to be any value except 80 such as

8080. Or else there will be a conflict to disable the virtual server.

4.5.2 Port Triggering

Choose menu “Forwarding→Port Triggering”, you can view and add port triggerings
