TL-R460 Cable/DSL Router User Guide
64
button to disable the function.
¾ Packets Statistics Interval - The default value is 10. Select a value between 5 and
60 seconds in the pull-down list. The Packets Statistic interval value indicates the
time section of the packets statistic.
¾ Sorted Rules - Select the rule for displaying the traffic information.
¾ Statistics Table - This table displays the statistics information about the traffic.
IP Address
The IP address whose statistics information are displayed
Packets
The total amount of packets received and transmitted by the router
Total
Bytes
The total amount of bytes received and transmitted by the router
Packets
The total amount of packets received and transmitted in the last “Packets
Statistic interval” seconds
Bytes
The total amount of bytes received and transmitted in the last “Packets
Statistic interval” seconds
ICMP Tx
The total amount of the ICMP packets transmitted to WAN in the last
“Packets Statistic interval” seconds
UDP Tx
The total amount of the UDP packets transmitted to WAN in the last
“Packets Statistic interval” seconds
Current
SYN Tx
The total amount of the TCP SYN packets transmitted to WAN in the last
“Packets Statistic interval” seconds
)
Note:
1)
If the Current Statistics Status function is disabled, the DoS protection in
Advanced Security will be ineffective.
2) Select the Auto-refresh, then the traffic information will be refreshed
automatically during the Packets Statistics Interval. Click the Refresh button to
refresh the information in the table immediately.
