TL-R460 Cable/DSL Router User Guide

the background.

2) If you are a Cable user, please configure the router following the above steps.

2. How do I configure the router to access Internet by Ethernet users?

Step 1: Login to the router, click the menu Network→WAN on the left of your browser,

On the WAN screen, select “Dynamic IP” for "WAN Connection Type", and

finish it by clicking Save.

Step 2: Some ISPs require that you register the MAC address of your adapter, which is

connected to your cable or DSL modem during installation. If your ISP requires

MAC register, login to the router and click the menu Network→MAC Clone. On

the MAC Clone screen, if your PC’s MAC address is a proper MAC address,

click the "Clone MAC Address To" button and your PC’s MAC address will be

filled in the "WAN MAC Address" field; Or else, enter the specific MAC address

into the "WAN MAC Address" field manually. Then click the Save button. It will

take effect after rebooting.

Figure B-3

3. I want to use Netmeeting, what do I need to do?

If you start Netmeeting as a sponsor, you don’t need to do anything with the router.

If you start as a responsor, you need configure Virtual Server or DMZ Host as follows:

Method one: Use Virtual Server

screen, add a Virtual Server rule as shown on the next screen: configure 1720 as the

“Service Port” and enter your IP address (assuming 192.168.0.102 for an example),

then click select the status Enabled and click Save.
