15
HOME > WAN > PPPOE
Choose PPPoE (Point to Point Protocol over Ethernet) if you’re ISP uses PPPoE
connection. Your ISP will provide you with a username and password. This option
is typically used for DSL services. Select Dynamic PPPoE to obtain an IP address
automatically for your PPPoE connection. Select Static PPPoE to use a static IP
address for your PPPoE connection.
Dynamic PPPoE PPPoE connection where you will receive an IP
address automatically from your ISP
Static PPPoE PPPoE connection where you have an assigned (static)
IP Address
User Name Your PPPoE username provided by your ISP
Password Your PPPoE password provided by your ISP
Retype Password Re-enter PPPoE password
Service Name Enter the service name provided by your ISP. (optional)
IP Address This option is only available for Static PPPoE. Enter in
the static IP address for the PPPoE connection.
Primary DNS Address Primary DNS IP provided by your ISP
Secondary DNS Address optional
Maximum Idle Time The amount of time of inactivity before disconnecting
your PPPoE session. Enter a Maximum Idle Time (in
minutes) to define a maximum period of time for which
Please
be sure to
remove any
existing PPPoE
Client Software
installed on your
computers.
