D-Link DGS-1100 MP/MPP Series Switch User Manual
39
10. PoE Scheduling
PoE Scheduling is a feature which allows you to specify the amount of time that power is delivered
to a PoE port. This can be used to save power when devices are not in use, or as a security
feature to prevent wireless access from being available outside of business hours, for example. It is
possible to set a schedule name, a start time, an end time and which ports the PoE schedule
applies to.
To view the following window, click on the PoE Scheduling link in the navigation menu:
Figure 10-1 PoE Scheduling Window
The fields that can be configured for the Time Profile are described below:
Parameter Description
Range Name
Enter a descriptive name for the PoE schedule.
Daily
Check this tick-box to enable the schedule daily and gray-out the
day-of-week fields in the From Time/To Time sections.
From Time (Day/Hour) The start day and time for the PoE schedule. Click the calendar
icon to pick this using a graphic calendar tool.
To Time (Day/Hour) The end day and time for the PoE schedule. Click the calendar
icon to pick this using a graphic calendar tool.
Click the Apply button to accept the changes made.
The fields that can be configured for the PoE Configuration are described below:
Parameter Description
From Port The start port in the range that the PoE schedule will apply to.
To Port The end port in the range that the PoE schedule will apply to.
