D-Link DGS-1100 MP/MPP Series Switch User Manual
50
Configuration Restore & Backup
Configuration Restore from HTTP
This window is used to initiate a configuration restore from a local PC using HTTP.
NOTE: If the switch is in HTTPS mode, the firmware or configuration cannot be upgraded using
regular HTTP.
To view the following window, click Tools > Configuration Restore & Backup > Configuration
Restore from HTTP, as shown below:
Figure 15-4 Configuration Restore from HTTP window
The fields that can be configured are described below:
Parameter Description
Source File
Enter the source filename and path of the configuration file
located on the local PC. Alternatively click the Browse button
to navigate to the location of the configuration file located on
the local PC.
Click the Restore button to initiate the configuration restore.
Click Effective immediately (running-config) to have the uploaded configuration loaded
immediately.
Click Take effect after the next boot (startup-config) to load the configuration after the switch has
been rebooted.
Configuration Backup to HTTP
This window is used to initiate a configuration file backup to a local PC using HTTP.
To view the following window, click Tools > Configuration Restore & Backup > Configuration
Backup to HTTP, as shown below:
Figure 15-5 Configuration Backup to HTTP window
Select Include username password to save the switch user accounts and passwords to the backup
file.
Select Exclude username password to save the switch user accounts and passwords to the
backup file.
Click the Backup button to initiate the configuration file backup.
