TD-W8960N 300Mbps Wireless N ADSL2+ Modem Router User Guide

Chapter 4. Configuring the Router

This chapter will show each Web page's key function and the configuration way.

4.1 Login

After your successful login, you will see the six main menus on the left of the Web-based utility. On

the right, there are the corresponding explanations and instructions.

The detailed explanations for each Web page’s key function are listed below.

4.2 Device Info

Choose “Device Info” menu, there are six submenus under the main menu: Summary, WAN,

Statistics, Route, ARP and DHCP. This Device Info section mainly introduces the elementary

information about the Router and its current settings in use. Click any of them, and you will be able

to view the corresponding information.

Choose “Device Info”“Summary”, you will see the Summary screen (shown in Figure 4-1). The

first table in

dicates the information about the version including Software and Hardware. The

second table displays the current status of the TD-W8960N connection. This information will vary

depending on the settings of the Router configured on the Advanced Setup screen.
