TD-W8960N 300Mbps Wireless N ADSL2+ Modem Router User Guide

Select the application from the drop-down list. If the list does not have the application that

you want, select the Custom application radio button, and type the name of the custom

application in the text box.

3. Enter the Trigger Port Start, Trigger Port End, Open Port Start and Open Port End in the

table, and then select the Trigger protocol and Open protocol, TCP, UDP or All.

4. Click Save/Apply to enable the settings and then you will see your settings as shown in

Figure 4-26.



Note:

If you select the application from the drop-down list, the External Port Start, External Port End,

Internal Port Start, Internal Port End and the Protocol will be added in the table automatically.

4.4.5.3 DMZ Host

Choose “Ad

vanced Setup”“NAT”“DMZ Host”, you can set up DMZ Host on the screen

(shown in Figure 4-28).

The DMZ host

feature can make a local host be exposed to the Internet for a special-purpose

service, such as online gaming or video conferencing.

Figure 4-28

To add a new DMZ Host:

You can enter the computer's IP address and then click Save/Apply to activate the DMZ host you

set on this page.



Note:

DMZ host forwards all the ports at the same time. Any PC whose port is being forwarded must

have its DHCP client function disabled and should have a new static IP Address assigned to it

because its IP Address may change while using the DHCP function.

4.4.5.4 ALG

Choose “Ad

vanced Setup”“NAT”“ALG”, and then you can configure the basic security in the

screen as shown in Figure 4-29.
