7
English
DEMOLITION HAMMER SAFETY
WARNINGS
1. Wear ear protectors.
Exposure to noise can cause hearing loss.
2. Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
3. Hold power tool by insulated gripping surfaces,
when performing an operation where the cutting
accessory may contact hidden wiring or its own
cord.
Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
ADDITIONAL SAFETY WARNINGS
1. Ensure that the power source to be utilized conforms
to the power requirements specifi ed on the product
nameplate.
2. Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, which could cause a serious
accident.
3. When the work area is removed from the power source,
use an extension cord of suffi cient thickness and rated
capacity. The extension cord should be kept as short as
practicable.
4. Do not touch the bit during or immediately after
operation. The bit becomes very hot during operation
and could cause serious burns.
5. Before starting to break, chip into a wall, fl oor or ceiling,
thoroughly confi rm that such items as electric cables or
conduits are not buried inside.
6. At the start of work, confi rm screw tightening.
7. When working at a highly elevated location, pay attention
to articles and persons below.
8. Wear protective shoes to protect your feet.
9. Wear a dust mask.
Do not inhale the harmful dusts generated in chiseling
operation. The dust can endanger the health of yourself
and bystanders.
10. Mounting the tool
○ To prevent accidents, make sure to turn the switch off
and disconnect the plug from the receptacle.
○ When using tools such as bull points, cutters, etc.,
make sure to use the genuine parts designated by our
company.
○ Clean the shank portion of the bull point. Then smear the
shank portion with the grease or machine oil.
11. Be sure to grip the handle and side handle or cylinder
case cover during work. Do not hold by the grip during
work. If you pull it by mistake, the bull point could jump
out.
12 RCD
The use of a residual current device with a rated residual
current of 30mA or less at all times is recommended.
NAMES OF PARTS (Fig. 1 – Fig. 10)
1
Tool Shank
2
Front Cap
3
Grip
4
Grip (B)
5
On-lock Switch
6
Trigger Switch
7
Handle
8
Nameplate
9
Brush Cap (Inside the Tail Cover)
0
Set screw (Under the Plate)
!
Plate
@
Tail Cover
#
Housing
$
Side Handle
%
Cylinder Case Cover
^
Band
&
Handle Bolt
*
Mount
(
Band attachment area
)
Carbon brush
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
H41MB2 : Demolition Hammer
Low Vibration Handle
To reduce the risk of injury, user must read
instruction manual.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2002/96/
EC on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
V
Rated voltage
P
Power Input
Bpm Full-load impact rate
kg
Weight
(According to EPTA-Procedure 01/2003)
Switching ON
Switching OFF
