05
Gigabit L2 Managed Switch
Introduction
When the PoE LED is on, the port LED is indicating the power supply status.
LEDs
LED Status Indication
PWR
On The switch is powered on.
Off The switch is powered off or power supply is abnormal.
Flashing Power supply is abnormal.
SYS
Flashing The switch works properly.
On/Off The switch works improperly.
PoE Max
On
The remaining PoE power≤
7W.
Flashing
The remaining PoE power keeps≤
7W after this LED
is on for 2 minutes.
Off
The remaining PoE power＞
7W.
FAN
Green All the fans work properly.
Yellow Not all the fans work properly.
Off The switch works improperly.
Speed or PoE
(Por t 1-24
）
Green
On The port is supplying power normally.
Flashing
The supply power exceeds the correponding port's
maximum power.
Yellow
On Overload or short circuit is detected.
Flashing Power-on self-test has failed.
Off Not providing PoE power on the port.
1000Base-X
(Port 25-28)
On
There is a device linked to the corresponding port.
Flashing
The corresponding SFP port is transmitting or receiving
data.
Off There is no device linked to the corresponding SFP port.
Console (RJ-45) Port
Designed to connect with the serial port of a computer or terminal for monitoring
and configuring the switch.
Console (USB) Port
Designed to connect with the USB port of a computer for monitoring and configuring
the switch. The switch has an RJ-45 console port and a micro-USB console port
available. Console input is active on only one console port at a time. By default, the
micro-USB connector takes precedence over the RJ-45 connector.
10/100/1000Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or
1000Mbps. Each 10/100/1000Mbps RJ45 port has a corresponding 1000Mbps LED.
SFP Port
Designed to install the SFP module. T2600G-28MPS features 4 individual SFP ports
and supports 1000M SFP module connection only.
