03
Gigabit L2 Managed Switch
Introduction
the switch. The switch has an RJ-45 console port and a micro-USB console port
available. Console input is active on only one console port at a time. By default, the
micro-USB connector takes precedence over the RJ-45 connector.
Console (RJ-45) Port
Designed to connect with the serial port of a computer or terminal for monitoring
and configuring the switch.
LEDs
LED Status Indication
PWR
On The switch is powered on.
Off The switch is powered off or power supply is abnormal.
Flashing Power supply is abnormal.
SYS
Flashing The switch works properly.
On/Off The switch works improperly.
10/100/
1000Mbps
(Port 1-48)
Green
On
A 1000Mbps device is linked to the corresponding port,
but no activity.
Flashing
A 1000Mbps device is linked to the corresponding port
and data is being transmitted or received.
Yellow
On
A 10/100Mbps device is linked to the corresponding
port, but no activity.
Flashing
A 10/100Mbps device is linked to the corresponding port
and data is being transmitted or received.
Off
No device is linked to the corresponding SFP port but
no activity.
Link/Act
(Port 49-52)
On
There is a device linked to the corresponding port.
Flashing
The corresponding SFP port is transmitting or receiving
data.
Off There is no device linked to the corresponding SFP port.
10/100/1000Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10Mbps, 100Mbps or
1000Mbps. Each 10/100/1000Mbps RJ45 port has a corresponding 1000Mbps LED.
SFP Port
Designed to install the SFP module. T2600G-52TS features 4 individual SFP ports
and supports 1000M SFP module connection only.
