Tp-Link T2600G-28MPS V1 [30/32] Q4 why does the terminal emulation program display abnormally

Gigabit L2 Managed Switch

Troubleshooting

Q4. Why does the terminal emulation program display abnormally?

Please check as follows:

1. Make sure the power supply is normal and the console cable is properly connected.

2. Check if the console cable is the right type.

3. Ensure the parameters of the terminal emulation program are same as you have

congured: congure Bits per second as 38400, Data bits as 8, Parity as None, Stop bits

as 1, and Flow control as None.
