Tp-Link T2600G-28MPS V1 [31/32] Appendix b hardware specifications
![Tp-Link T2600G-28MPS V1 [31/32] Appendix b hardware specifications](/views2/1471191/page31/bg1f.png)
25
Gigabit L2 Managed Switch
Hardware Specifications
Appendix B Hardware Specifications
Item Content
Standards
IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab,
IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p,
IEEE 802.1q, IEEE 802.1x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w
IEEE 802.3af/at (For T2600G-28MPS only)
Transmission Medium
10Base-T: UTP/STP of Cat. 3 or above
100Base-TX: UTP/STP of Cat. 5 or above
1000Base-T: 4-pair UTP (≤100m) of Cat. 5e, and Cat. 6 or
above
1000Base-X: MMF or SMF SFP Module (Optional)
LEDs
T2600G-28TS: PWR, SYS, 1000Mbps, Link/Act
T2600G-52TS: PWR, SYS, 10/100/1000Mbps (Port 1-48),
Link/Act (Port 49-52)
T2600G-28MPS: PWR, SYS, PoE Max, FAN, Speed or PoE
(Port 1-24), 1000Base-X (Port 25-28)
Operating Temperature 0℃~40℃
Storage Temperature -40℃~70℃
Operating Humidity 10%~90%RH Non-condensing
Storage Humidity 5%~90%RH Non-condensing
