JetStream 24-Port Gigabit Stackable Smart Switch with 4 10GE SFP+ Slots

09Installation

Figure 2-4 Stacking Using SFP+ Port

25 26

SFP+

27 28

SFP+ cable

Power On Sequence of the Stack Switches

Since the sequence in which the switches are first powered on might affect the switch

that becomes the stack master, please consider the following guidelines before

powering on the switches in the stack:

1. If you want a particular switch to become the stack master, power on this switch

first. After 1 minute, power on the other switches in the stack. That earliest startup

switch will remain the stack master until the next master re-election.

2. If you have no preference as to which switch becomes the stack master, power on all

the switches in the stack within 1 minute. The switches will participate in a election

to select a master. The Master LED of the selected switch will be on. The switches

powered on after 1 minutes don't participate in the election, and they will become

member switches.

3. You can access to any member of the stack via Web/SSH/Telnet connection, thus to

manage all the switches in the stack.

For more information about stack topology and master election, please refer to "Stack"

chapter in the User Guide on the Resource CD.

Caution:

In the process of using TP-LINK SFP+ Cables, please never bend them into a

radius of 45mm (1.77 inch) or less, because it may permanently damage the SFP+

Cables.
