JetStream 24-Port Gigabit Stackable Smart Switch with 4 10GE SFP+ Slots
22
Appendix B Specications
Appendix B Specifications
Item Content
Standards
IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3ad, IEEE802.3ae, IEEE802.3z,
IEEE802.3x, IEEE802.1p, IEEE802.1q, IEEE802.1x, IEEE802.1d, IEEE802.1s,
IEEE802.1w
Transmission Medium
10Base-T 2-pair UTP/STP of Cat. 3 or above (maximum 100m)
100Base-TX 2-pair UTP/STP of Cat. 5 or above (maximum 100m)
1000Base-T 4-pair UTP/STP of Cat. 5e and Cat. 6 or above (maximum 100m)
1000Base-SX MMF SFP Module
1000Base-LX MMF or SMF SFP Module
1000Base-LX10 SMF SFP Module
1000Base-BX10 SMF SFP Module
10GBASE-SR MMF SFP+ Transceiver
10GBASE-LR SMF SFP+ Transceiver
Transfer Method Store-and-Forward
MAC Address Learning Automatically learning, automatically aging
Frame Forward Rate
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
1000Base-T: 1488095pps/Port
1000Base-X: 1488095pps/Port
10GBASE-SR:14880952pps/Port
10GBASE-LR:14880952pps/Port
LEDs PWR, SYS, Master, Link/Act, 1000M, 25, 26, 27, 28, Unit ID LED
Operating Temperature 0
℃
to 40
℃
(32
℉
~104
℉
)
Storage Temperature -40
℃
to 70
℃
(-40
℉
~158
℉
)
Operating Humidity 10% to 90%RH Non-condensing
Storage Humidity 5% to 90%RH Non-condensing
