Managing System Managing User Account
User Guide
23
4
Managing User Account
With user account management, you can modify the username and password to refuse
illegal users.
Choose the menu System > User Account to load the following page.
Figure 4-1 Managing the User Account
Follow these steps to configure the user account:
1) Specify the user name, enter the old password, specify a new password and confirm
the new password.
User Name Create a user name for login. The user name should not be more than 16
characters using digits, letters and underlines only.
Old Password Enter the old password of the switch. By default, the old password is
admin.
New Password Specify a new password for login.
Confirm
Password
Retype the new password.
2) Click Apply.
