Monitoring Configuring Loop Prevention
User Guide
49
5
Configuring Loop Prevention
Choose the menu Monitoring > Loop Prevention to load the following page.
Figure 5-1 Configuring Loop Prevention
Follow these steps to configure loop prevention:
1) Select the loop prevention status as Enable or Disable from the drop-down list.
Loop Prevention
Status
Enable or disable the loop prevention feature globally.
2) Click Apply.
