Managing System Upgrading the Firmware
User Guide
31
3) Click Upgrade Firmware to load the following page. Click Yes to upgrade the firmware.
Figure 8-4 Being Sure to Upgrade the Firmware
Note:
•
It will take a moment to upgrade the firmware. Wait without any operation.
•
Select the proper software version matching with your hardware to upgrade.
•
To avoid damage, do not power down the switch while upgrading the firmware.
•
After upgrading, the switch will reboot automatically.
•
It is recommended to backup the configuration before upgrading.
