Evolis Quantum2 [10/18] Ä connecting the encoders to a port of the internal usb hub
![Evolis Quantum2 [10/18] Ä connecting the encoders to a port of the internal usb hub](/views2/1484002/page10/bga.png)
ä
(Items colored red)
It is suggested to power the contactless encoder from one connector, and the encoder for
contact smart card from the other encoder, so that the power supply is distinct for each encoder.
For example:
l J24: Encoder for contactless smart cards
l J27: Encoder for contact smart cards
The choice between these two connectors is left to the technician.
To avoid failures, check that the intensity during operation does not exceed
the maximum intensity delivered by Quantum (see Consumption chart in
Appendix 2).
ä
(Items colored yellow)
Connecting a smart card encoder or any other additional component (barcode reader, for
example) may be done using one of the two ports from
’s internal USB hub.
Generally, such accessories are self powered through the USB port. To avoid
any failure, check that the intensity during operation does not exceed
the maximum intensity delivered by Quantum (see Consumption chart in
Appendix 2).
J24
J24-1: GND (Masse)
J24-2: GND (Masse)
J24-3: GND (Masse)
J24-4: GND (Masse)
J24-5: + 3,3V
J24-6: + 5V
J24-7: + 5V
J24-8: + 24V
Type: HE14 – 1 x 8
J27
J27-1: GND (Masse)
J27-2: GND (Masse)
J27-3: GND (Masse)
J27-4: GND (Masse)
J27-5: + 3,3V
J27-6: + 5V
J27-7: + 5V
J27-8: + 24V
J27-9: + 24V
J27-10: + 3,3V
Type: HE14 – 1 x 10
J6 and J31
J6-1: +5V
J6-2: D-
J6-3: D+
J6-4: GND (Ground)
Type: HE14 – 1 x 4
9
