Evolis Quantum2 [13/18] Ä monitoring the contactless smart card encoder rs232 or ttl
![Evolis Quantum2 [13/18] Ä monitoring the contactless smart card encoder rs232 or ttl](/views2/1484002/page13/bgd.png)
ä
(Items colored blue)
This chapter describes how to connect a contactless smart card encoder with an integrated or
remote antenna.
The antenna-connecting process varies according to the encoder prole and is therefore not
addressed in the manual.
J11 and J14 are directly wired to the DB9 connector (J15).
The user can choose to connect one HE 14 (9-pin connector), or 2 HE10 (5-pin connector). This has
no impact on features and signals.
J12
J12-1: RXD1 TTL (In)
J12-2: TXD1 TTL (Out)
J12-3: TXD2 TTL (Out)
J12-4: RXD2 TTL (In)
J12-5: GND (Masse)
Type: HE14 – 1 x 5
TTL signals of the MAX232 (U23)
component
J9
J9-1: Ne pas utiliser
J9-2: TXD1 RS232 (In)
J9-3: RXD1 RS232 (Out)
J9-4: Ne pas utiliser
J9-5: GND (Masse)
J9-6: Ne pas utiliser
J9-7: RXD2 RS232 (Out)
J9-8: TXD2 RS232 (In)
J9-9: Ne pas utiliser
J9-10: Ne pas utiliser
Type: HE10 – 2 x 5
RS232 signals of the MAX232
(U23) component
On the computer side:
J9-2 = R x D
J9-3 = T x D
J9-7 = RTS
J9-8 = CTS
J11
J11-1: DB9-1
J11-2: DB9-2
J11-3: DB9-3
J11-4: DB9-4
J11-5: DB9-5
J11-6: DB9-6
J11-7: DB9-7
J11-8: DB9-8
J11-9: DB9-9
J11-10: Ne pas utiliser
Type: HE10 – 2 x 5
Directly wired to J15 (DB9
connector)
J14
J14-1: DB9-1
J14-2: DB9-2
J14-3: DB9-3
J14-4: DB9-4
J14-5: DB9-5
J14-6: DB9-6
J14-7: DB9-7
J14-8: DB9-8
J14-9: DB9-9
Type: HE14 – 1 x 9
Directly wired to J15 (DB9
connector)
J15
Directly wired to J15 (DB9
connector)
12
