Evolis Quantum2 [11/18] Ä monitoring the smart contact station
![Evolis Quantum2 [11/18] Ä monitoring the smart contact station](/views2/1484002/page11/bgb.png)
ä
(Items colored brown)
J17
J17-1: Smart C1 Vcc
J17-2: Smart C2 RST
J17-3: Smart C3 CLK
J17-4: Smart C4 Reserved
J17-5: Smart C5 GND (Masse)
J17-6: Smart C6 Vpp
J17-7: Smart C7 I/O
J17-8: Smart C8 Reserved
J17-9: Smart OPTO+
J17-10: Smart OPTO-
Type: HE10 – 2 x 5
OPTO+ and OPTO- : Signals the
presence of a card
J18
J18-1: DB9-1
J18-2: DB9-2
J18-3: DB9-3
J18-4: DB9-4
J18-5: DB9-5
J18-6: DB9-6
J18-7: DB9-7
J18-8: DB9-8
J18-9: DB9-9
Type HE10 – 2 x 5
Connected to J19
(DB9 Contact external
connector)
OPTO- is grounded (GND)
J21
J21-1: Smart OPTO+
J21-2: Smart OPTO-
Type: HE14 – 1 x 2
OPTO+ and OPTO-: Signals the
presence of a card
J22
Jumper from J22-1 to J22-2
Card in contact with Smart
station = OPTO closed
Card is not available = OPTO
open
Factory setting
Jumper from J22-2 to J22-3
Card in contact with Smart
station = OPTO open
Card absent = OPTO closed
Type: HE14 – 1 x 3
Specication of how card-
presence signal is performed
OPTO open :
OPTO closed :
J19 DB9 external connector (female)
10
