Evolis Quantum2 [5/18] Chapter 3 using the reversible mode



The encoding module is reversible. This means it can turn over and proceed to card encoding

and printing in a single pass, without having to ip each and every card over:

l Encoding position A: Magnetic encoding on the reverse side, and chip encoding on the front

side (factory settings), or

l Encoding position B: magnetic encoding on the front side and chip encoding on the reverse

side

Flipping the encoding module over requires that the machine be switched off, and that the power

cable be disconnected to avoid any damage to the electronic boards and the encoders.

Flipping the encoding module over requires that the machine be switched

off, and that the power cable be disconnected to avoid any damage to the

electronic boards and the encoders.



Despite the attention paid to the manufacture and quality of our products, the need to replace

the encoding module may arise over the lifetime of the machine.

The module can be replaced by the user with no tools needed, simply by following the instructions

very carefully.

Before doing anything else, please contact your Evolis dealer in order to check the advisability of

replacing the encoding module. The dealer will supply a new encoding module if need be.

Under these circumstances, the following procedure will need to be scrupulously carried out, in

order to keep very high quality encoding, copying the properties and settings for the replacement

module in the printer.
