These data are necessary to help you quickly and correct-
ly. These data are available on the supplied rating plate.
Model description .................
Product number (PNC) .................
Serial Number (S.N.) .................
Use the original spare parts only. They are available at
Service Force Centre and approved spare parts shops.
Technical data
Hob dimensions
Width: 580 mm
Length: 500 mm
Hob recess dimensions
Width: 550 mm
Length: 470 mm
Heat input
Rapid burner: 3.0 kW
Semi-rapid burner: 2.0 kW
Auxiliary burner: 1.0 kW
TOTAL POWER: G20 (2H) 20 mbar = 8 kW
G30 (3B/P) 30 mbar =
567 g/h
G31 (3B/P) 30 mbar =
557 g/h
Electric supply: 230 V ~ 50 Hz
Gas connection: G 1/2 "
Category: II2H3B/P
Gas supply: G20 (2H) 20 mbar
Appliance class: 3
By-pass diameters
Burner Ø By-pass in 1/100 mm
Auxiliary 28
Semi-rapid 32
Rapid 42
Gas burners
BURNER
NORMAL POW-
ER
REDUCED
POWER
NORMAL POWER
NATURAL GAS
G20 (2H) 20 mbar
LPG
(Butane/Propane) G30/G31
(3B/P) 30/30 mbar
kW kW
inj. 1/100
mm
m³/h
inj. 1/100
mm
g/h
Auxiliary 1.0 0.33 70 0.095 50 73
Semi-rapid 2.0 0.45 96 0.190 71 145
Rapid
3.0 (natural gas)
2.8 (LPG)
0.75 119 0.285 86 204
22
