Zanussi ZOB580N [17/52] What to do if
![Zanussi ZOB580N [17/52] What to do if](/views2/1049519/page17/bg11.png)
cleaning is carried out, refit the oven door, following the
procedure in reverse.
Stainless steel or aluminium appliances:
We recommend that the oven door is only cleaned using a
wet sponge and dried after cleaning with a soft cloth.
Never use steel wool, acids or abrasive products as they
can damage the oven surface. Clean the oven control pan-
el following the same precautions.
Warning! DO NOT clean the oven door while the
glass panels are warm. If this precaution is not
observed the glass panel may shatter.
If the door glass panel becomes chipped or has deep
scratches, the glass will be weakened and must be
replaced to prevent the possibility of the panel shattering.
Contact your local Service Centre who will be pleased to
advise further.
Replacing the oven light
Disconnect the appliance from the electrical supply.
If the oven bulb needs replacing, it must comply with the
following specifications:
• Electric power: 15 W/25 W;
• Electric rate: 230 V (60 Hz);
• Resistant to temperatures of 300°C;
• Connection type: E14.
These bulbs are available from your local Service Force
Centre.
To replace the faulty bulb
1. Ensure the oven is isolated from the electrical sup-
ply.
2. Push in and turn the glass cover anticlockwise.
3. Remove the faulty bulb and replace with the new
one.
4. Refit the glass cover and restore the electrical sup-
ply.
Grill heating element
This model has been fitted with a hinged grill element to
make the roof of the oven especially easy to clean.
Warning! Before proceeding ensure the oven is cool
and disconnected from the electricity supply.
1
Undo the screw fas-
tening the grill element.
When carrying out this op-
eration for the first time,
we recommend using a
screwdriver.
2
Then gently pull the
grill downwards to allow
access to the oven roof.
Clean the oven roof with a suitable cleaner and wipe dry
before returning the hinged grill element to its original po-
sition.
Carefully push the grill element up into its original posi-
tion and re-tighten the retaining nut.
Warning! Ensure the retaining nut on the grill
element is properly tightened so that it does not fall
down when in use.
What to do if…
If the appliance is not working correctly, please check the
following before contacting the Electrolux Service Centre.
17
