Operating Manual for Wood Splitter English Troubleshooting the hydraulics Problem Cause Solution Hydraulic splitting cylinder does not move Drive shaft broken Contact an authorised dealer Shaft coupling slack Contact an authorised dealer Gearwheel areas damaged Contact an authorised dealer Pressure relief valve damaged Contact an authorised dealer Hydraulic splitting cylinder moves slowly to and from Hydraulic cylinder leaking Engine is running but wood is not being split or is being split too slowly Hydraulic lines blocked Contact an authorised dealer Oil level too high low Check oil level Control valve damaged blocked Contact an authorised dealer Gearwheel areas damaged Contact an authorised dealer Engine speed too low Set throttle on the engine to Pressure relief valve damaged Contact an authorised dealer Oil level too high low Check oil level Oil contaminated Contact an authorised dealer Control valve leaking internally Contact an authorised dealer Cylinder damaged internally Contact an authorised dealer Seals broken Contact an authorised dealer Cylinder run in Contact an authorised dealer Small gearwheel area damaged Contact an authorised dealer Non return valve of the pump leaking Contact an authorised dealer Oil level too high low Check oil level Oil contaminated Contact an authorised dealer Control valve leaking internally Contact an authorised dealer Cylinder overloaded Do not attempt to split wood against the grain Cylinder damaged internally Contact an authorised dealer Engine stalls during the splitting process Too little power weak engine Contact an authorised dealer Cylinder overloaded Do not attempt to split wood against the grain Engine is not running or stalls under load Hydraulic pump defective Contact an authorised dealer Engine has too little power Contact an authorised dealer Hydraulic lines control valve blocked Contact an authorised dealer Drive shaft broken Contact an authorised dealer Gearwheel areas damaged Contact an authorised dealer Shaft seal defective Contact an authorised dealer Vent hole in the oil tank blocked Ensure that the tank has been vented correctly Pump shaft seal leaking Note Contact an authorised customer service for repairs which go beyond the measures mentioned above 11
