100
EB140
EB140
Hot melt edgebanders
| Automatic hot melt edgebander
Specifications
Tape height 45 mm for tapes from 0.4 to 2 mm
Tape height 25 mm for tapes of 3 mm
Min/max panel thickness 13/45 mm
Min. panel length/width 140/65 mm
Panel feeder speed 5 m/min
Trimming unit speed 10,000/min
Trimming bits Ø 60 mm 4Z R2+10º
Roller holder capacity 590 mm
Glue pot capacity 1 kg
Working temperature 175-210°C
Feeder motor power 0.18 kW
Trimming unit motor power 0.37 kW
Gluing unit motor power 0.09 kW
Weight 260 kg
The EB140 edgebander must be connected to an external dust collec-
tion system like our dust collector model AS382L (optional), with a big
dust collection capacity and prepared to work during the trimming
cycles automatically.
The accessibility to the different parts of the machine is easy and comfortable. The EB140 has several
doors and movable elements making easy the different adjustments.
External dust collection for pipes of
100 mm diameter. To be connected
to dust collection systems with a
minimum air flow of 1000 m
3
/h.
Optional accessories
6399082 Cantspray. Silicone free anti-
adhesive spray.
8599694 Netspray. Multi-purpose cleaner
for effortless removal of adhesive residue.
8599611 Lubricating oil 30 ml.
8546317 Locking kit for end trimmer (for
banding laminates)
8599634 Container of glue 3 kg
Bits included as standard equipment
8540183 Upper bit Ø 60 Z4, r:2, 10° bevel
8540184 Lower bit Ø 60 Z4, r:2, 10° bevel
Optional bits
8540172 Upper bit Ø 60 Z4, r:3, 10° bevel
8540173 Lower bit Ø 60 Z4, r:3, 10° bevel
8540185 Upper bit Ø 60 Z4, 45° bevel
8540186 Lower bit Ø 60 Z4, 45° bevel
