Virutex EB135 [42/116] Trimmers
![Virutex EB135 [42/116] Trimmers](/views2/1506739/page42/bg2a.png)
42
FR217S
Trimmers
Specially designed for trimming
the concave radiuses in the joints
between rims and work tops made
of materials such as Corian or Rau-
solid. Fitted with a front feeler that
prevents the rim from becoming
damaged and allows for quick, easy
trim ming, giving a perfect finish.
Equipped with a powerful 750 W mo-
tor with electronic speed adjustment
and constant torque control for a
constant motor speed under load.
Delivered with two special carbide
bits for radius 5 and 10 mm. The
machine is also fitted with a dust
collection connector.
Perfect finishing, total integration of the rim and the work top, leaving
them like a single piece.
First trimming.
Specifications
Input power 750 W
No-load speed 14,000-30,000/min
Chuck collet 8 mm
Max. bit diameter 20 mm
Weight 1.6 kg
Standard equipment
Radius bit R5 HM (1740306)
Radius bit R10 HM (1740307)
Chuck collet 8 mm
Carrying case
R5 R10
Optional bits
1740311 Carbide radius bit R6
1740312 Carbide radius bit R8
Trimming process in
two passes
2nd trimming
1st trimming
| Angle trimmer
