22
PDE446L
RO156N
Sanders & grinders
Specifications
Input power 700 W
Disc diameter 173 mm
No-load speed 2,000-3,800/min
Weight 3 kg
Auxiliary straight grinder, equipped
with 6 mm chuck collet, for metal
finishings and roughdressings. It can
be used with most standard grinding
accessories on the market. Electronic
speed control.
Optional collets
1222085 Chuck collet Ø 6.35 mm (1/4”)
1222024 Chuck collet Ø 8 mm
Specially designed for sheet metal
and marble sanding work. Its power-
ful 700 W motor provides the heavy
duty sturdiness required for heavy
work without fatigue. Standard
equipment includes a rubber disc
and sanding disc.
Equipped with electronic speed
control.
Ideal for sheet steel work.
Sanding marble.
| Straight grinder| Disc sander
Specifications
Input power 750 W
No-load speed 14,000-30,000/min
Standard collet capacity 8 mm
Max. wheels Ø 40m/s. 25 mm
Spindle flange diameter 43 mm
Weight 1.3 kg
Sanding discs: see pag. 23
It allows to make finishings and
roughdressings in metals.
(Grinding tool not included)
