23
Sanding papers
Sanding material
Sanding belts
All sanding sheets have dust collection holes.
Ref. Description Models
6791058 50 Sheets Gr. 50 (c) LR46L, LRE46L
6791059 50 Sheets Gr. 80 (c) LR46L, LRE46L
6791057 50 Sheets Gr. 120 (c) LR46L, LRE46L
6791060 50 Sheets Gr. 150 (c) LR46L, LRE46L
4691072 50 Sheets Gr. 100 (c) LR46L, LRE46L
8691073 50 Sheets Gr. 50 115x208 c/velcro (c) LR46L, LRE46L
8691074 50 Sheets Gr. 80 115x208 c/velcro (c) LR46L, LRE46L
8691075 50 Sheets Gr. 120 115x208 c/velcro (c) LR46L, LRE46L
8691076 50 Sheets Gr. 150 115x208 c/velcro (c) LR46L, LRE46L
9391064 50 Sheets Gr. 60 (c) LR84H, LRE84H, LRT84H
9391063 50 Sheets Gr. 80 (c) LR84H, LRE84H, LRT84H
9391062 50 Sheets Gr. 120 (c) LR84H, LRE84H, LRT84H
9391061 50 Sheets Gr. 150 (c) LR84H, LRE84H, LRT84H
8491097 50 Sheets Gr. 100 LR84H, LRE84H, LRT84H
8491089 50 Sheets Gr. .40 81x132 velcro LR84H, LRE84H, LRT84H
9391068 50 Sheets Gr. 60 81x132 velcro LR84H, LRE84H, LRT84H
9391067 50 Sheets Gr. 80 81x132 velcro LR84H, LRE84H, LRT84H
9391066 50 Sheets Gr. 120 81x132 velcro LR84H, LRE84H, LRT84H
9391065 50 Sheets Gr. 150 81x132 velcro LR84H, LRE84H, LRT84H
8491090 50 Sheets Gr. 220 81x132 velcro LR84H, LRE84H, LRT84H
8491091 50 Sheets Gr. 400 81x132 velcro LR84H, LRE84H, LRT84H
8491098 50 Sheets Gr. 50 93x230 LR284R
8491099 50 Sheets Gr. 80 93x230 LR284R
8491100 50 Sheets Gr. 120 93x230 LR284R
8491101 50 Sheets Gr. 150 93x230 LR284R
8491102 50 Sheets Gr. 100 93x230 LR284R
8491103 50 Sheets Gr. 40 93x185 velcro LR284R
8491104 50 Sheets Gr. 60 93x185 velcro LR284R
8491105 50 Sheets Gr. 80 93x185 velcro LR284R
8491106 50 Sheets Gr. 120 93x185 velcro LR284R
8491107 50 Sheets Gr. 150 93x185 velcro LR284R
8491108 50 Sheets Gr. 220 93x185 velcro LR284R
8491109 50 Sheets Gr. 400 93x185 velcro LR284R
Ref. Description Models
8491083 50 Delta sandpaper Gr. 40 velcro LR84H, LRE84H, LRT84H
8491084 50 Delta sandpaper Gr. 60 velcro LR84H, LRE84H, LRT84H
8491085 50 Delta sandpaper Gr. 80 velcro LR84H, LRE84H, LRT84H
8491086 50 Delta sandpaper Gr. 120 velcro LR84H, LRE84H, LRT84H
8491087 50 Delta sandpaper Gr. 220 velcro LR84H, LRE84H, LRT84H
8491088 50 Delta sandpaper Gr. 400 velcro LR84H, LRE84H, LRT84H
Ref. Description Models
4591020 1 Sanding disc Gr. 120
(without dust collection holes)
PDE446L
Sanding sheets
Delta sanding sheets
Sanding disc for PDE446L
Sanding discs
Ref. Description Models
4691025 50 Discs Gr. 40 (Ø150) self-adhesive RTE46/146L, RT188N
4691026 50 Discs Gr. 60 (Ø150) self-adhesive RTE46/146L, RT188N
4691027 50 Discs Gr. 80 (Ø150) self-adhesive RTE46/146L, RT188N
4691024 50 Discs Gr. 120 (Ø150) self-adhesive RTE46/146L, RT188N
4691028 50 Discs Gr. 150 (Ø150) self-adhesive RTE46/146L, RT188N
4691029 50 Discs Gr. 220 (Ø150) self-adhesive RTE46/146L, RT188N
4691030 50 Discs Gr. 320 (Ø150) self-adhesive RTE46/146L, RT188N
4691045 50 Discs Gr. 40 (Ø150) velcro RTE46/146L, RT188N
4691046 50 Discs Gr. 60 (Ø150) velcro RTE46/146L, RT188N
4691047 50 Discs Gr. 80 (Ø150) velcro RTE46/146L, RT188N
4691055 50 Discs Gr. 120 (Ø150) velcro RTE46/146L, RT188N
4691048 50 Discs Gr. 150 (Ø150) velcro RTE46/146L, RT188N
4691049 50 Discs Gr. 220 (Ø150) velcro RTE46/146L, RT188N,
4691050 50 Discs Gr. 320 (Ø150) velcro RTE46/146L, RT188N
8491077 50 Discs Gr. 40 (Ø 125) velcro RTE84H, LRT84H
8491078 50 Discs Gr. 60 (Ø 125) velcro RTE84H, LRT84H
8491079 50 Discs Gr. 80 (Ø 125) velcro RTE84H, LRT84H
8491080 50 Discs Gr. 120 (Ø 125) velcro RTE84H, LRT84H
8491081 50 Discs Gr. 220 (Ø 125) velcro RTE84H, LRT84H
8491082 50 Discs Gr. 400 (Ø 125) velcro RTE84H, LRT84H
All sanding discs have dust collection holes.
All sanding sheets have dust collection holes.
The sanding discs marked with (c) are only
recommended for woodworking and the rest for
woodworking and sanding metals.
Ref. Description Models
4491022 10 Belts 690x100 Gr. 30 LB31E, LB31EA, AF11
4491006 10 Belts 690x100 Gr. 40 LB31E, LB31EA, AF11
4491007 10 Belts 690x100 Gr. 50 LB31E, LB31EA, AF11
4491008 10 Belts 690x100 Gr. 60 LB31E, LB31EA, AF11
4491009 10 Belts 690x100 Gr. 80 LB31E, LB31EA, AF11
4491010 10 Belts 690x100 Gr. 100 LB31E, LB31EA, AF11
Ref. Description Models
9791114 Cement, rough surfaces, wallpaper
Gr.24 (10 u.)
LPC97S, LPM97S
9791115 Filler, paint, rough sanding Gr.40 (25 u.) LPC97S, LPM97S
9791116 Filler, paint, rough sanding Gr.60 (25 u.) LPC97S, LPM97S
9791117 Filler, paint, rough sanding Gr.80 (25 u.) LPC97S, LPM97S
9791118 Filler, paint, rough sanding Gr.100 (25 u.) LPC97S, LPM97S
9791119 Filler, paint, rough sanding Gr.120 (25 u.) LPC97S, LPM97S
9791120 Filler, paint, rough sanding Gr.150 (25 u.) LPC97S, LPM97S
9791121 Filler, paint, rough sanding Gr.180 (25 u.) LPC97S, LPM97S
9791122 Filler, paint, rough sanding Gr.220 (25 u.) LPC97S, LPM97S
Sanding discs for LPC97S & LPM97S
