RC 2 | RC 5 basic and control
/// Energy-ecient recirculating chillers
Due to the high energy eciency of our R134a-based refrigeration machine, a
significantly lower amount of greenhouse gases is emitted over the life span of the
product compared to unregulated chillers using natural coolants.
Even in the worst-case scenario, IKA devices have the advantage of saving
500 g/kWh CO
2
in the current energy mix after just 1.5 years, compared to
unregulated devices with natural coolants. (Assumptions: coolant has dissipated
completely at the end of the product life cycle; GWP for R134a = 1,300,
according to IPCC AR5 100 years, 250 work days/year; 2 kWh savings/day).
With the launch of the RC 5, IKA is offering, for the first time, a recirculating chiller
with natural coolant R 290. Adding the innovative on-demand control, IKA is
contributing to a green future.
DURING THE DEVELOPMENT OF THE RC RECIRCULATING CHILLERS, IKA ENGINEERS
STRONGLY FOCUSED ON ENERGY EFFICIENCY AND DEVELOPING UNIQUE SOLUTIONS.
› The heart of the RC 2 and RC 5 is a speed-controlled compressor, which is used to respond to the actual
cooling need. The energy consumption can be reduced significantly as well as the compressor service life
increased.
› The high-quality foam insulation, surrounding the storage tank, minimizes the energy input and keeps
the bath fluid cool.
› The air-cooled microchannel condenser ensures optimal heat dissipation. The air flow, required for the
micro-channel condenser, is generated by a speed-controlled fan. It reduces the noise level and lowers
energy consumption.
› The electronically controlled expansion valve contributes to achieving an excellent temperature stability
of up to ± 0.05 K.
Simple handling of cooling
fluids due to the large opening
and the integrated funnel
Easy-to-clean air filter
Safety drain at the front
IKA RECIRCULATING CHILLER –
ENVIRONMENTALLY FRIENDLY
