IKA ICC basic pro 12 0010000414 [28/37] Accessories
![IKA ICC basic pro 20 c 0008036000 [28/37] Accessories](/views2/1545687/page28/bg1c.png)
Information: eco - water, + 100 °C | pro - water, oil, + 200 °C
IB 18 eco
Plastic bath, 18l
IB HF 24 eco
Plastic bath,
tall form, 24l
IB 9 pro
Stainless steel bath, 9l
IB 20 pro
Stainless steel bath, 20l
IB R RO15 eco
for magnetic stirrer RO 15
BS.ICC
Bridge
CS.ICC
Cover
Floating globes, PP
› out of Polypropylene
› for covering
open water baths
› only for water
› ø 20 mm
› 500 pcs.
Ident. No. 0020003666
€ 105,00
Accessories
/// Baths and covers
Bath type
Outer dimensi-
ons [mm]
Inner dimensi-
ons [mm] Price
Bath size S
IB 8 eco,
Ident. No. 0004248100
Plastic bath,
8 l 335 × 320 × 155 286 × 227 × 150 € 309,00
IB R 9 eco,
Ident. No. 0020004382
Plastic bath,
9 l, rectangular
356 × 287 × 167 307 × 239 × 151 € 330,00
IB 9 pro,
Ident. No. 0004248500
Stainless steel
bath, 9 l
377 × 374 × 195 292 × 230 × 150 € 435,00
Bath size M
IB 12 pro,
Ident. No. 0004577500
Stainless steel
bath, 12 l 461 × 354 × 195 317 × 292 × 150 € 496,00
Bath size L
IB 18 eco,
Ident. No. 0004248200
Plastic bath,
18 l 584 × 338 × 155 490 × 286 × 150 € 435,00
IB 24 HF eco,
Ident. No. 0020006884
Plastic bath,
24 l, tall form
584 × 338 × 205 490 × 286 × 200 € 495,00
IB R 20 eco,
Ident. No. 0020004383
Plastic bath,
20 l, rectangular
552 × 365 × 167 504 × 317 × 151 € 440,00
IB R 52 eco,
Ident. No. 0020007044
Plastic bath,
52 l, rectangular
648 × 365 × 316 600 × 317 × 300 € 605,00
IB R RO 15 eco,
Ident. No. 0020006341
Plastic bath,
for magnetic
stirrer RO 15
722 × 365 × 165 674 × 317 × 98 € 770,00
IB 20 pro,
Ident. No. 0004248600
Stainless steel
bath, 20 l
641 × 354 × 195 495 × 292 × 150 € 596,00
Suitable for
the following sizes Price
ICC
Bridge BS.ICC,
Ident. No. 0020003077 S € 117,00
Bridge BL.ICC
Ident. No. 0020003078
M + L € 117,00
Cover CS.ICC
Ident. No. 0004471500
S € 122,00
Cover CM.ICC
Ident. No. 0025000290
M € 155,00
Cover CL.ICC
Ident. No. 0004471600
L € 155,00
IC
Bridge BS.IC,
Ident. No. 0004472800 M + L € 117,00
Cover CM.IC
Ident. No. 0004577600
M € 117,00
Cover CL.IC
Ident. No. 0004471800
L € 155,00
BATH VESSELS
/// Comparison
BRIDGE AND COVER
/// Comparison
56
57
