RC 2 | RC 5 basic and control
/// Energy-ecient recirculating chillers
The RC cooling circulators are designed for fast and ecient cooling of external
devices. The chillers distinguish themselves by short cooling times with a temperature
stability of up to ± 0.05 K. The operating temperature range is from room temperature
down to - 30 °C. The maximum recirculation temperature is + 80 °C. You can adjust
the pump performance as needed through the speed-controlled pressure and suction
pump; hence exceeding the cooling power according to DIN.
The control devices are equipped with a connector for an external temperature sensor.
Using the PT 100 temperature probe (within scope of delivery), you can control the
temperature directly in your target medium.
The device can be operated conveniently via the RC 2 | 5 control WiCo (wireless
controller). It makes the chiller space-saving and allowing for it to be placed in even
hard-to-reach areas of the lab.
Control accuracy – the speed-regulated
compressor provides a ten-times higher
temperature stability of up to ± 0.05 K.
Energy eciency – up to 60 % lower
energy consumption during standard opera-
tion (compared to devices of competitors).
Silent mode –
the fan only runs as needed.
Handling – safe and ergonomic handling
due to a well thought-out design. Casters
on the back of the device enable easy
transport and set-up.
Large operating volume – the large
difference between the maximum and
minimum volume can be used as the
operating volume for external tempering.
NEW!
THE IKA RECIRCULATING CHILLER HAS A BROADER
OPERATING TEMPERATURE RANGE OF UP TO + 80 °C
THE RC 2 CONTROL COOLS DOWN TO - 30 °C
(50 W COOLING POWER AT 3,200 RPM)
RC 2 | 5 control – connection for PT 100
temperature probe.
RC 2 | 5 control – detachable WiCo
(wireless controller) for simple and safe
remote access from up to 10 m (30 ft.).
RC 5 basic and control
Recirculating chillers
RC 2 basic and control
Recirculating chillers
44
45
