Ident. No. 0020017366
€ 8.900,00
Ident. No. 0020017364
€ 3.900,00
labworldsoft
®
software
/// Advanced software with an innovative visual
approach to lab automation
IKA‘s software labworldsoft
®
enables the networking of up to
64 laboratory devices which can be controlled simultaneously
via one PC. Not only IKA products, but also other manufacturers
laboratory devices can be integrated using labworldsoft
®
.
This makes the automation of your laboratory experiments and
processes much more easy and ecient.
Calibration and adjustment
/// Two-point or three-point calibration
The internal (and external, if used) temperature sensor can be adjusted via
either a two-point or three-point calibration process. On request, calibrati-
on can also be performed in the plant by the IKA service team or by an
external, ISO- and DAkks certified service provider.
If you would like to request this service, please contact our service depart-
ment by telephone at 00 8000 4524357 (00 8000 IKAHELP) or by email
service@ika.de.
Windows 7/8.1/10 (64-bit operating system) with at least 2 GB
RAM and 100 MB free hard disc memory. Some devices require
the installation of a specific device driver. Communications
interfaces can be retrofitted using an adapter at the PC, if
necessary.
HARDWARE AND SOFTWARE REQUIREMENTS
/// labworldsoft
®
Software
TRY IT FOR YOURSELF
Get your free, fully functional 30 day trial
version download at: www.labworldsoft.com
labworldsoft
®
6 Pro
labworldsoft
®
6 Lite
70
71
Temperature control productsTemperature control products
