IKA ICC basic pro 12 0010000414 [27/37] Scope of delivery
![IKA ICC basic pro 12 0010000414 [27/37] Scope of delivery](/views2/1545687/page27/bg1b.png)
Scope of delivery
/// Temperature control instruments
ICC
basic
ICC
control
IC
basic
IC
control
HBC 5 | 10
basic
HBC 5 | 10
control
Pump connection set × × × ×
Cooling coil CC 1 × × ×
PT 100 interface × × × × ×
External PT 100 probe
USB interface × × × × × ×
RS 232 interface × × × × × ×
Multi IO interface × ×
1 x USB cable (station) × × × × × ×
1 x USB cable (WiCo) × ×
Charger for WiCo × ×
Power cable × × × × × ×
Barb fittings for DN 12 hoses (2 ×) × × × ×
Barb fittings for DN 8 hoses (2 ×)
WiCo wall mount
SCOPE OF DELIVERY
/// Comparison
Heating
CBC 5
basic
CBC 5
control
HRC 2
basic
HRC 2
control
RC 2 | 5
basic
RC 2
control
RC 5
control
Pump connection set × × × × × × ×
Cooling coil CC 1
PT 100 interface × × × × ×
External PT 100 probe × ×
USB interface × × × × × × ×
RS 232 interface × × × × × × ×
Multi IO interface × × ×
1 x USB cable (station) × × × × × × ×
1 x USB cable (WiCo) × × × ×
Charger for WiCo × × × ×
Power cable × × × × × × ×
Barb fittings for DN 12 hoses (2 ×) × × × × × × ×
Barb fittings for DN 8 hoses (2 ×) × × × × ×
WiCo wall mount × ×
Heating and Cooling
× = included with delivery
