Temperature control productsTemperature control products
Accessories
/// Temperature control instruments
Description Connection Price
MV 1
Ident. No. 0020003763
Solenoid valve for cooling water
regulation, 0 to + 90 °C, max. 10 bar 2 hose olives DN8 included € 368,00
CO V 1
Ident. No. 0002000049
Shut-off valve for external
tempering, - 40 °C to - 180 °C,
max. 1 bar
Directly on circulator, second
page for hose olives M 16 × 1
€ 560,00
Ball valve M 16 × 1
Ident. No. 0020004620
Manually operated ball valve
With union nut on one side for
mounting on M 16 × 1 thread.
Second connection M 16 × 1
€ 75,00
Description Unit of measure Price
Barb fitting for DN 6 hoses
Ident. No. 0020004667
Barb fitting adapter for
DN 6 hose 2 € 30,00
Barb fitting for DN 8 hoses
Ident. No. 0020004566
Barb fitting adapter for
DN 8 hose
2 € 25,00
Barb fitting for DN 10 hoses
Ident. No. 0020004568
Barb fitting adapter for
DN 10 hose
2 € 30,00
Barb fitting for DN 12 hoses
Ident. No. 0020004889
Barb fitting adapter for
DN 12 hose
2 € 25,00
Adapter NPT 1/4
Ident. No. 0020004569
Adapter M 16 × 1 to
NPT 1/4 (male)
2 € 37,00
Adapter NPT 1/2
Ident. No. 0020004570
Adapter M 16 × 1 to
NPT 1/2 (male)
2 € 117,00
Adapter NPT 3/4
Ident. No. 0020004571
Adapter M 16 × 1 to
NPT 3/4
2 € 140,00
Lock nut M 16 × 1
Ident. No. 0020004583
Nut for mounting hose barb fitting
adapters, stoppers, NPT adapters
2 € 35,00
Stopper
Ident. No. 0020004584
For sealing purposes, used in
combination with a lock nut
2 € 35,00
Elbow tube 90°
Ident. No. 0025001212
90° tube adapter, e.g. used for
connecting hoses without creating
a bend
1 € 70,00
Description Price
PCS.ICC
Ident. No. 0004471900 Pump connection set for ICC € 135,00
PT 100.30
Ident. No. 0004284700
Temperature probe, stainless steel, 250 mm € 279,00
PT 100 extension (Lemo)
Ident. No. 0020004629
Extension cable PT 100, lemo connector, 3 m € 165,00
WH 10
Ident. No. 0020000984
WiCo (wireless controller) wall mount € 17,00
PC 1.1
Ident. No. 0002616700
RS 232 cable, 3 m (10 ft) € 31,00
labworldsoft
®
6 Pro
Ident. No. 0020017366
Laboratory software € 8.900,00
labworldsoft
®
6 Lite
Ident. No. 0020017364
Laboratory software € 3.900,00
SOLENOID VALVES
/// Comparison
HOSE BARB FITTINGS AND ADAPTERS
/// Comparison
FURTHER ACCESSORIES
/// for temperature control instruments
64
CC1
› Cooling coil for IC basic
CC2
› Cooling coil for ICC
MV 1
CO V 1
Mechanic fluid
level controller
› Fluid level monitor for opera-
ting heating bath circulators or
coolers on open baths.
Ident. No. 0020005116
€ 123,00
Ident. No. 0025001061
€ 115,00
Ident. No. 0020004618
€ 300,00
Barb fitting for
6 mm/8 mm
Barb fitting adapter
Stopper
for sealing purposes
Lock nut M 16 × 1
for mounting hose
barb fitting adapters
Elbow tube 90°
90° tube adapter
Adapter NPT 1/4
Adapter M 16 × 1 to
NPT 1/4 (male)
Adapter NPT 1/2
Adapter M 16 × 1 to
NPT 1/2 (male)
Adapter NPT 3/4
Adapter M 16 × 1 to
NPT 3/4 (male)
