Tempera-
ture range
Viscosity
at + 25 °C Color Quantity Price
Heating Fluids
HF.Si.20.250.50 A
Ident. No. 0020003521
+ 20 °C to
+ 250 °C* 50 mm²/s
reddish-
translucent 10 kg € 450,00
HF.Si.20.200.50
Ident. No. 0020003520
+ 20 °C to
+ 200 °C**
50 mm²/s clear 10 kg € 400,00
Universal Fluid
UF.Si.N30.150.10 LV
Ident. No. 0020003518
- 30 °C to
+ 150 °C*** 10 mm²/s clear 9 kg € 400,00
SILICON-BASED TEMPERATURE CONTROL FLUIDS
/// Comparison
* + 250 °C only in enclosed baths (HBC), otherwise + 200 °C
** + 250 °C only for a short time in enclosed baths
*** + 130 °C in open baths
Accessories
/// Bath fluids
UF. Si. N20.150. 20 LV
Additional information
› Low viscosity (LV)
› Contains additives (A)
ViscosityChemical basis
› Silicon (Si)
Minimum/
maximum temperature
Bath fluid type
› Heating fluid (HF)
› Universal fluid (UF)
Temperature [°C]
Viscosity [mm
2
/s]
60
50
40
20
10
0
-30 10 50 13090 170 210 250 290
30
UF.Si.150.N30.10 LV
HF.Si.20.200.50
HF.Si.20.250.50A
60
61
