Your Life, our Quality. Worldwide. 27 3D SERIES

The contents of this publication must not be regarded as binding. EBARA Pumps Europe S.p.A. reserves the right to effect any modiﬁcation it deems necessary, without prior notice.

3D SERIES

centrifugal pumps close coupled and standardized en 733

MATERIALS TABLE

Ref. Name Material

001 Pump casing CastironEN-GJL-250-EN1561

003 Motorbracket [1]

004 Sealhousingdisc EN1.4301(AISI304)

006 Rotorshaft(partincontactwiththeliquid) EN1.4301(AISI304)

007 Impeller [2]

011 Mechanicalseal Ceramic/Carbon/NBR

012 Motorframe -

013 Motorcover Aluminium

014 Fan PA

015 Fancover FeP04Galvanized

016 Terminalbox -

017 Terminalboxcover Aluminium(threephaseonly)

018 Sprayprotectorwasher NBR

019 Bearing(pumpside) -

020 Bearing(motorside) -

021 Adjusting ring SteelC70

022

Tie-rod Fe42Galvanized

Screw Galvanizedsteel8.8classISO898-1

024 Plug Brass

025 Plug Brass

026 O-Ring NBR[3]

032 Key EN1.4401(AISI304)

034 Impellernut EN1.4301(AISI304)

042 Motorsupport Aluminium/Galvanizedsteel

056 Terminalboxgasket NBR

058 Cablegland -

072 Casingring[4] EN1.4301(AISI304)

075 Washer Aluminium

076 Washer Aluminium

092 Seal ring -

093 Seal ring -

101 Seeger ring [5] CarbonsteelTC80

200 Screw Galvanizedsteel8.8classISO898-1

235 Washer Galvanizedsteel

206 Screw(support)[6] Galvanizedsteel8.8classISO898-1

[1]=CastironEN-GJL-200-EN1561for3DSERIES32-200/3andmodelsfrom15,18.5and22kW;aluminiumAL-EN-1706-AC-46000-Dfortherestoftherange

[2]=EN1.4301(AISI304)for3DSERIES32,40,50;EN1.4401(AISI316)for3DSERIES65

[3]=FPMforH,HS,HW,HSWversions;EDPMforEversion

[4]=Onlyfor3DSERIES32-200,40-200,50-160,50-200

[5]=Onlyfor9,2and11kWmodels

[6]=Onlyfor11kWmodels
