5
English
M502
Optional Wired Remote Control Unit Operations
Following operations are enabled by remote control with the separately sold Wired Remote Control Unit
MW1 (shown below), MW2 or MW3.
Note:
If the remote control is connected with this unit while the power on, please restart this unit again to
conrm the normal display.
[
MENU/BAND]
[
ENTER]
[ [ /SOURCE]]
[ ], [ ]
[ ]
[ ]
[ ], [ ]
IR-Receiver
[ /SOURCE] button
• Press the [ /SOURCE] button to turn the
power on and press and hold it (1 sec.) to
turn the power off.
• Each time the [ /SOURCE] button is
pressed, the mode switches.
Note:
• If the above equipment is not connected,
correspondingmodecannotbeselected.
[ENTER] button
• ALL mode – Answer(incoming) / Transfer call
(During talking -> press)
• RADIO mode – No function
• USB mode – Conrm (in Menu mode)
• iPod mode – Conrm (in Menu mode)
• AUX mode – No function
• PANDORA mode – Bookmark Artist / song
(long press) / Conrm (in Menu mode)
• SiriusXM mode – Jump to Alert ch / Conrm
ch (in Search mode)
• BT mode – Answer(incoming) / Call(from
CALL LIST) / Transfer call(During talking ->
press)
[
], [ ] buttons
• Press the [ ] button to increase the volume.
• Press the [
] button to decrease the volume.
[ ], [ ] buttons
• RADIO mode – Station up-down /Seek up-
down (long press)
• USB mode – Previous-next track / Fast
forward-reverse(long press)
• iPod mode – Previous-next track / Fast
forward-reverse(long press)
• AUX mode – No function
CAUTION
Lower the volume level before powering
the source unit off. The source unit
stores the last volume setting.
WARNING
When the front panel is open, no sound
is produced, and source unit controls
and remote control unit operations are
disabled. Always shut the front panel
after changing the CD.
EXPOSING THE UNIT TO WATER
WITH TH E FRONT PANE L OPEN
WILL CA U S E DAMA G E OR UNIT
MALFUNCTION!
Remote Control (RCX003)
Notes of remote control using
Replacing the lithium battery of remote control unit.
When the range of the operation of the card remote control becomes short or no functions while
operating. Replace the battery with a new lithium battery. Make sure the battery polarity replacement is
correct.
1. Pull out the battery holder while pressing the stopper.
2. Insert the button-type battery with the stamped(+) mark facing upward.
Insert the battery holder into the remote control.
[SRC/
] Button
• Toggle the audio source
•
Power on ( short press) / off (long press)
[ , ] Buttons
• Preset station up / down
• Previous / next track
• Search (long press)
[SCN/PS/AS] Button
• Scan play / Preset scan
• Auto memory store (long press)
• SiriusXM mode – Channel scan (in
current category) / Preset scan (long
press)
[BAND/TOP] Button
• MP3/WMA mode – Top play (long press)
• SiriusXM mode – Select tuner band,
quit Replay(Replay mode) / Select
category(long press)
• PNADORA mode – Skip song
[
, ] Buttons
• Volume up / down
[
] Button
• Play / Pause
• SirusXM mode – Replay mode
[ISR] Button
• Recall ISR station stored in memory
• Store current station in ISR memory (long
press)
• SiriusXM mode – iTunes Tagging (When
connected with SiriusXM Vehicle Tuner
and displayed ”TAG” on display)
[DISP] Button
• Display switch
[RDM] Button
• Random play
• SiriusXM mode – Tune to alerted station
[RPT] Button
• Repeat play
• SiriusXM mode – Add Artist Alert / Add Song
Alert (long press)
• PANDORA mode – Bookmark song / Artist
(long press)
[MUTE] Button
• Mute the volume
[1~6] Buttons
• [1] Button: Preset station 1.
• PANDORA mode – Create new station
• [2] Button: Preset station 2.
• [3] Button: Preset station 3.
• [4] Button: Preset station 4.
• [5] Button: Preset station 5.
• PANDORA mode – Thumbs down
• [6] Button: Preset station 6.
• PANDORA mode – Thumbs up
[SOUND] Button
• Sound effect setting
(CR 2025)
CR 2025
[ , ]
[ISR]
[RPT]
[SOUND]
[RDM]
[ , ]
[DISP]
[1~6]
[MUTE]
[SCN/
PS/AS]
[ ]
[BAND/TOP]
[SRC/ ]
