ABB ACH550-01-04A1-4+B055 [13/32] Start stop direction control
![ABB ACH550-01-04A1-4+B055 [13/32] Start stop direction control](/views2/1556846/page13/bgd.png)
ACH550 BACnet User’s Manual 13
Start-up
Start/Stop Direction Control
Using the fieldbus for start/stop/direction control of the drive requires:
• Drive parameter values set as defined below.
• Fieldbus controller supplied command(s) in the appropriate location.
Note: Ext1 = Ref 1
Ext 2 = Ref 2; Ref 2 normally used for PID setpoint commands.
Input Reference Select
Using the fieldbus to provide input references to the drive requires:
• Drive parameter values set as defined below.
• Fieldbus controller supplied reference word(s) in the appropriate location.
Miscellaneous Drive Control
Using the fieldbus for miscellaneous drive control requires:
• Drive parameter values set as defined below.
• Fieldbus controller supplied command(s) in the appropriate location.
Drive Parameter Value Description
BACnet
Access Point
1001 EXT1 COMMANDS COMM (10) Start/Stop by fieldbus with Ext1 selected. BV10
1002 EXT2 COMMANDS COMM (10) Start/Stop by fieldbus with Ext2 selected. BV10
1003 DIRECTION REQUEST (3) Direction by fieldbus-if required. BV11
Drive Parameter Value Description BACnet Access Point
1102 EXT1/EXT2 SEL COMM (8) Reference set selection by fieldbus. BV13
1103 REF1 SEL COMM (8) Input reference 1 by fieldbus. AV16
1106 REF2 SEL COMM (8) Input reference 2 by fieldbus. AV17
Drive Parameter Value Description
BACnet Access
Point
1601 RUN ENABLE COMM (7) Run enable by fieldbus (not
recommended).
BV12
1604
FAULT RESET SEL COMM (8) Fault reset by fieldbus. BV14
1608 START ENABLE 17 (COMM) Source for start enable 1 is the fieldbus
Command word (not recommended).
BV20
1609
START ENABLE 27 (COMM) Source for start enable 2 is the fieldbus
Command word (not recommended).
BV21
