28 ACH550 BACnet User’s Manual
Technical Data
Analog Output Object Instance Summary
The following table summarizes the Analog Output Objects supported:
Note! For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
Analog Value Object Instance Summary
The following table summarizes the Analog Value Objects supported:
Instance
ID
Object Name Description Units
Present Value
Access Type
AO0 AO 1
COMMAND
This object controls Analog Output 1. The
corresponding drive parameter is 0135,
COMM VALUE 1. Control requires parameter
1501 value = 135.
Percent C
AO1 AO 2
COMMAND
This object controls Analog Output 2. The
corresponding drive parameter is 0136,
COMM VALUE 2. Control requires parameter
1507 value = 136.
Percent C
Instance
ID
Object Name Description Units
Present Value
Access Type
AV0 OUTPUT
SPEED
This object indicates the calculated motor
speed in RPM. The corresponding drive
parameter is 0102.
RPM R
AV1 OUTPUT FREQ This object indicates the output
frequency applied to the motor in Hz. The
corresponding drive parameter is 0103.
Hertz R
AV2 DC BUS VOLT This object indicates the drive’s DC bus
voltage level. The corresponding drive
parameter is 0107.
Volts R
AV3 OUTPUT VOLT This object indicates the AC output
voltage applied to the motor. The
corresponding drive parameter is 0109.
Volts R
AV4 CURRENT This object indicates the measured
output current. The corresponding drive
parameter is 0104.
Amps R
AV5 TORQUE This object indicates the calculated motor
output torque as a percentage of nominal
torque. The corresponding drive
parameter is 0105.
Percent R
AV6 POWER This object indicates the measured
output power in kW. The corresponding
drive parameter is 0106.
Kilowatts R
AV7 DRIVE TEMP This object indicates the measured
heatsink temperature in °C. The
corresponding drive parameter is 0110.
°C R
