ACH550 BACnet User’s Manual 29
Technical Data
AV8 KWH (R) This object indicates, in kW hours, the
drive’s accumulated energy usage since
the last reset. The value can be reset to
zero. The corresponding drive parameter
is 0115.
kWh W
AV9 MWH (NR) This object indicates the drive’s
accumulated energy usage inMW hours.
The value cannot be reset.
MWh R
AV10 PRC PID FBCK This object is the Process PID feedback
signal. The corresponding drive
parameter is 0130.
Percent R
AV11 PRC PID DEV This object is the Process PID output
signal’s deviation from its setpoint. The
corresponding drive parameter is 0132.
Percent R
AV12 EXT PID FBCK This object is the External PID feedback
signal. The corresponding drive
parameter is 0131.
Percent R
AV13 EXT PID DEV This object is the External PID output
signal’s deviation from its setpoint. The
corresponding drive parameter is 0133.
Percent R
AV14 RUN TIME (R) This object indicates, in hours, the drive’s
accumulated run time since the last reset.
The value can be reset to zero. The
corresponding drive parameter is 0114.
Hours R
AV15 MOTOR TEMP This object indicates the drive’s motor
temperature, as set up in parameter
Group 35. The corresponding drive
parameter is 0145.
°C R
AV16 INPUT REF 1 This object sets Input Reference 1.
Control requires parameter 1103 value =
COMM.
Percent C
AV17 INPUT REF 2 This object sets either:
• Input Reference 2. Control requires
parameter 1106 value =
COMM.
• Process PID setpoint. Control requires
parameter 1106 value =
PID1 OUT and
parameter 4010 value =
COMM.
Percent C
AV18 LAST FLT This object indicates the most recent fault
entered in the drive’s fault log. The
corresponding drive parameter is 0401.
None R
AV19 PREV FLT 1 This object indicates the second most
recent fault entered in the drive’s fault
log. The corresponding drive parameter
is 0412.
None R
AV20 PREV FLT 2 This object indicates the third most recent
fault entered in the drive’s fault log. The
corresponding drive parameter is 0413.
None R
AV21 AO 1 ACT This object indicates Analog Output 1’s
level. The corresponding drive parameter
is 0124.
Milliamps R
Instance
ID
Object Name Description Units
Present Value
Access Type
