26 ACH550 BACnet User’s Manual
Technical Data
BV9 RUN ENA ACT This object indicates the Run
Enable command status,
regardless of the control
source.
ENABLE/
DISABLE
R
BV10 RUN/STOP CMD This object commands a drive
start. Control requires either:
• Parameter 1001 value =
COMM for control by EXT1
or
• Parameter 1002 value =
COMM for control by EXT2.
RUN/STOP C
BV11 FWD/REV CMD This object commands a
motor rotation direction
change. Control requires
1003 =
REQUEST and either:
• Parameter 1001 value =
COMM for control by EXT1
or
• Parameter 1002 value =
COMM for control by EXT2.
REV/FWD C
BV12 RUN ENA CMD This object commands Run
Enable. Control requires
parameter 1601 value =
COMM.
ENABLE/
DISABLE
C
BV13 EXT 1/2 CMD This object selects ext1 or
ext2 as the active control
source. Control requires
parameter 1102 value =
COMM.
EXT2/EXT1 C
BV14 FAULT RESET This object resets a faulted
drive. The command is rising-
edge triggered. Control
requires parameter 1604
value =
COMM.
RESET/NO C
BV15 MBOX READ This object reads a parameter
(defined by AV25
MBOX
PARAM) and returns it in AV26
MBOX DATA.
READ/RESET W
BV16 MBOX WRITE This object writes the data
value specified by AV26,
MBOX DATA, to a parameter
(defined by AV25,
MBOX
PARAM).
WRITE/RESET W
BV17 LOCK PANEL This object locks the panel
and prevents parameter
changes. The corresponding
drive parameter is 1602.
LOCK/UNLOCK W
BV18 CTL OVERRIDE
CMD
This object commands the
drive into BACnet Control
Override. In this mode,
BACnet takes drive control
from the normal source.
However, the control panel’s
HAND mode has priority over
BACnet Control Override.
ON/OFF C
Instance
ID
Object Name Description
Active/Inactive
Text
Present Value
Access Type
