ACH550 BACnet User’s Manual 27
Technical Data
Note! For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
Analog Input Object Instance Summary
The following table summarizes the Analog Input Objects supported:
Note! For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
BV19 CTL OVERRIDE
ACT
This object indicates whether
the drive is in BACnet Control
Override. (See BV18.)
ON/OFF R
BV20 START ENABLE 1 This object commands start
enable1. Control requires
parameter 1608
value=COMM.
ENABLE/
DISABLE
C
BV21 START ENABLE 2 This object commands start
enable1. Control requires
parameter 1608
value=COMM.
ENABLE/
DISABLE
C
Instance
ID
Object Name Description Units
Present Value
Access Type
AI0 ANALOG INPUT 1 This object indicates the value of
Analog Input 1. The corresponding
drive parameter is 0120.
Percent R
AI1 ANALOG INPUT 2 This object indicates the value of
Analog Input 2. The corresponding
drive parameter is 0121.
Percent R
Instance
ID
Object Name Description
Active/Inactive
Text
Present Value
Access Type
