30 ACH550 BACnet User’s Manual
Technical Data
Note! For Present Value Access Types, R = Read-only, W = Writeable,
C = Commandable. Commandable values support priority arrays & relinquish
defaults.
AV22 AO 2 ACT This object indicates Analog Output 2’s
level. The corresponding drive parameter
is 0125.
Milliamps R
AV23 ACCEL1 TIME This object sets the Ramp1 acceleration
time. The corresponding drive parameter
is 2202.
Seconds W
AV24 DECEL1 TIME This object sets the Ramp1 deceleration
time. The corresponding drive parameter
is 2203.
Seconds W
AV25 MBOX PARAM This object defines the parameter to be
read or written to by the mailbox function.
See BV15 and BV16.
None W
AV26 MBOX DATA This object holds the mailbox function’s
parameter value – a value that was read,
or is to be written. See BV15 and BV16.
None W
AV27 EXT PID STPT This object sets the External PID
controller setpoint. The corresponding
drive parameter is 4211. Control requires
parameter 4210,
PID SETPOINT SEL, value
= 19 (
INTERNAL).
Percent C
Instance
ID
Object Name Description Units
Present Value
Access Type
