16 ACH550 BACnet User’s Manual
Diagnostics
Diagnostics
Fault Queue for Drive Diagnostics
For general ACH550 diagnostics information, see “Diagnostics” in the ACH550
User’s Manual. The three most recent ACH550 faults are reported to the fieldbus as
defined below.
Serial Communication Diagnostics
Network problems can be caused by multiple sources. Some of these sources are:
• Loose connections
• Incorrect wiring (including swapped wires)
• Incorrect baud rate
• Bad grounding
• Duplicate station numbers
• Incorrect setup of drives or other devices on the network
The major diagnostic features for fault tracing on an EFB network include Group 53
EFB Protocol parameters 5306…5309. The “Parameter Descriptions” section, in the
ACH550 User’s Manual, describes these parameters in detail.
Diagnostic Situations
The sub-sections below describe various diagnostic situations – the problem
symptoms and corrective actions.
Normal Operation
During normal network operation, 5306…5309 parameter values act as follows at
each drive:
• 5306 EFB OK MESSAGES advances (advances for each application message
properly received and addressed to this drive).
• 5307 EFB CRC ERRORS does not advance at all (advances when an invalid
message CRC is received).
• 5308 EFB UART ERRORS does not advance at all (advances when character format
errors are detected, such as parity or framing errors).
• 5309 EFB status value varies depending on network traffic.
Drive Parameter BACnet Access Point
0401 Last Fault AV18
0412 Previous Fault 1 AV19
0413 Previous Fault 2 AV20
