Actual signals and parameters 57
6004 PV CELL MIN
VOLT
Defines the minimum DC voltage below which the
inverter cannot operate.
Note: The inverter stops operating below this voltage.
1 = 1 V
109...800 V DC voltage.
Note: Range is different for 1-phase and 3-phase
inverters.
400 V unit:
225
200 V unit:
129
6005 PV CELL MAX
VOLT
Defines the maximum DC voltage. At any value above
this voltage, the inverter trips due to PV MAX VOLT
fault.
1 = 1 V
109...800 V DC voltage.
Note: Range is different for 1-phase and 3-phase
inverters.
400 V unit:
640
200 V unit:
368
6006 PUMP
MINIMUM SPD
Defines the minimum motor speed. At any value below
this speed, the inverter stops functioning and auto
restarts after the time defined in 6019 FAULT RESET
TIME. This setting avoids unnecessary operation of
pump at low speed.
1 = 1 rpm
0...3000 rpm Speed 0
6007 PUMP
MAXIMUM SPD
Defines the maximum motor speed.
1 = 1 rpm
0...3000 rpm Speed 3000
6008 BOOST VOLT Defines the DC voltage above which 6009 BOOST
FACTOR is effective. Below this value, motor speed
follows the V/F factor.
1 = 1 V
109...600 V DC voltage.
Note: Range is different for 1-phase and 3-phase
inverters.
400 V unit:
450
200 V unit:
259
6009 BOOST
FACTOR
Defines the factor at which the inverter functions the
best. This parameter is effective when DC voltage is
above the value in 6008 BOOST VOLT.
100 = 1
0.75...1.25 Boost factor 1.00
6015 DRY RUN SEL
DI
Selects the input for dry run protection. WITH_
P60.16
DI1 Digital input DI1. Defines the digital input DI1 as the
control for dry run protection.
1
DI2 See selection DI1.2
All parameters
No. Name/
Value
Description Def/ FbEq
