40
Figure
a) Push the handle into the suction pipe/telescopic tube.
To remove it, turn the handle slightly and pull it off the
tube.
b) Push the handle straight into the telescopic tube until it
engages.
To release the connection, squeeze the collar sleeve and
pull the handle out.
Figure
a) Connect the floor tool and the telescopic tube together.
b) Push the telescopic tube straight into the
connecting piece of the floor tool until it engages.
To release the connection, squeeze the locking collar
and pull the telescopic tube out.
Figure
a) Connect the suction pipes together, or
b) Unlock the telescopic tube to adjust its length by moving
the sliding switch in the direction of the arrow.
Figure
Holding the power cord by the plug, pull out the required
length and plug it into the mains socket.
Figure
Press the on/off button in the direction of the arrow to
switch your vacuum cleaner on/off.
Controlling the suction level
Figure
The required suction level can be set to the level
required by turning the control knob in the direction
of the arrow.
䡲
Low suction range =>
For vacuuming delicate fabrics,
e.g. curtains.
䡲
Medium suction range =>
For daily vacuuming of lightly
soiled floors.
䡲
High suction range =>
For vacuuming durable floor
coverings, hard floors and for
heavily soiled surfaces.
Vacuuming
Figure
Adjusting the floor tool:
䡲
Rugs and carpets =>
䡲
Hard surfaces =>
Caution!
Floor tools are subject to a certain amount of wear,
depending on the type of hard floors you have
(e.g. rough, rustic tiles). Therefore, you must check
the underside of the floor tool at regular intervals.
Worn undersides of floor tools may have sharp edges
that can damage sensitive hard floors, such as parquet
or linoleum. The manufacturer does not accept any
responsibility for damage caused by worn floor tools.
10
9
8
7
6*
5*
4*
Figure
Remove the upholstery nozzle and crevice nozzle from
the accessories holder as illustrated.
Figure
Vacuuming with accessories
Attach the nozzles to the suction pipe or handle as
required:
a) Crevice nozzle for vacuuming crevices and corners, etc.
b) Upholstery nozzle for vacuuming upholstered furniture,
curtains, etc.
c) Hard furnishings brush
For cleaning window frames, cabinets, mouldings, etc.
d) Hard-floor brush
For vacuuming hard floor coverings (tiles, parquet
flooring, etc.)
Figure
After use, push the crevice nozzle and upholstery nozzle
back into the accessories holder as indicated.
Turbo brush
If your vacuum cleaner is equipped with a turbo brush,
please consult the accompanying instruction manual
fornotes on use and maintenance.
Figure
You can use the parking aid on the side of the vacuum
cleaner if you wish to stop vacuuming for a short time.
Once you have switched off the vacuum cleaner, slide
the catch on the floor tool into the groove on the side of
the appliance.
Figure
The appliance can also be carried using one of the two
handles when vacuuming steps, for example.
When the work is done
Figure
Unplug the vacuum cleaner.
Tug the power cord briefly and let go. The cable then
rewinds automatically.
Figure
To store or transport the vacuum cleaner, use the storage
aid on the underside of the vacuum cleaner.
Stand the vacuum cleaner up on its end. Slide the catch
on the floor tool into the groove on the underside of the
appliance.
17
16
15
14
13
12*
11
